TESCOM 2in. Brass Pressure Gauge Max Pressure 400 PSI / 28 Bar

Name: TESCOM 2in. Brass Pressure Gauge Max Pressure 400 PSI / 28 Bar
Brand: TESCOM
SKU: 62838-0400N20
Price: 84.00 USD
Availability: InStock

SKU

62838-0400N20

$84.00

Restrictions / Notifications

Non-Returnable/Non-Cancelable
This item cannot be canceled or returned once an order has been placed.

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Specs

More Information

Applications

Designed for general, laboratory, and semiconductor applications involving the measurement of compressed gases compatible with the materials of construction.
For gaseous media.
Gas filling pressure indicator on cylinder regulators.
Machine building and general plant construction.

Specifications

Pressure Gauge Material: Brass
Bourdon Tube Material: Phosphor bronze, beryllium copper or stainless steel, depending on gauge style and pressure
1/4 in. NPT
Diameter: 2 in.
Scale: Multiscale (psi / bar)
Maximum Pressure: 400 psi / 28 bar
Accuracy (Brass): ASME B40.1 Grade B, middle half of scale - 2% of scale range, remainder: 3%
Movement (Brass): Quality brass construction with gears precision generated and bearing surfaces finely finished, ensuring smooth motion and extended service life
Cleaning: ASME B40.1 Level IV
