TESCOM 2in. 316 SS Pressure Gauge, 1/4in. NPT (10,000 PSI / 690 Bar)

Name: TESCOM 2in. 316 SS Pressure Gauge, 1/4in. NPT (10,000 PSI / 690 Bar)
Brand: TESCOM
SKU: 62837-10000N20
Price: 153.00 USD
Availability: InStock

SKU

62837-10000N20

$153.00

Restrictions / Notifications

Non-Returnable/Non-Cancelable
This item cannot be canceled or returned once an order has been placed.

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Specs

More Information

Applications

Designed for general, laboratory and semiconductor applications involving the measurement of compressed gases compatible with the materials of construction
For gaseous media
Gas filling pressure indicator on cylinder regulators
Machine building and general plant construction

Specifications

Pressure Gauge Material: 316 stainless steel
Bourdon Tube Material: Phosphor bronze, beryllium copper or stainless steel, depending on gauge style and pressure
1/4 in. NPT
Diameter: 2 in.
Scale: Multiscale (psi / bar)
Maximum Pressure: 10,000 psi / 690 bar
Accuracy (Stainless Steel): Grade A, middle half of scale - 1% of scale range, remainder 2%
Movement (Stainless Steel): Glasstuf links with stainless steel pins
Cleaning: ASME B40.1 Level IV
