Cygnus 004-9550 | T2C Twin 2 MHz 17/12 mm Lemo 00

• Designed by Cygnus specifically to measure heavily corroded metals in either Echo-Echo or Single-Echo mode.
• Twin crystal transducers are particularly suited to measuring heavily corroded metals.
• They are used with our thickness meters in two measuring modes.
• In Echo-Echo mode, up to 0.040 in. of surface coating can be completely ignored: only the underlying material thickness will be displayed.
• Single-Echo mode should only be used when there are no coatings or paints on the material being measured.

• Cygnus 2+ Hands-Free Multi-Mode Ultrasonic Thickness Gauge
• Cygnus 4 General Purpose Multiple Echo Thickness Gauge
• Cygnus 4+ General Purpose Multi-Mode Ultrasonic Thickness Gauge
• Cygnus 6+ PRO Multi-Mode Ultrasonic Thickness Gauge

• Frequency: 2 MHz
• Crystal Diameter: 0.5 in. (12 mm)
• Tip Size: 0.67 in. (17 mm)
• Range in Steel:
  • Single-Echo: 0.1-13.8 in. (2.5-350 mm)
  • Echo-Echo: 0.20-2 in. (5-50 mm)
• Connector: Twin Lemo 00
• Weight: 1.98 oz. (56 g)
• Temperature Range: 14°F to 158°F (-10°C to 70°C)

NOTE: This probe requires Cygnus Probe Lead Twin Lemo 00 to Twin Lemo 00 - P/N: 004-0411 (sold separately).
