Circle Seal Check Valve Brass 1/2in. MNPT, 2-5 PSIG CP

• Designed for high pressure service
• Resilient O-ring
• Single piece design
• Less susceptible to contamination damage
• Zero leakage at normal back pressure
• Automatic compensation for wear
• Cushioned, quiet closing

• Materials:
  • Body: Brass
  • O-Ring: Neoprene
• Connection Size: 1/2 in. MNPT X 1/2 in. MNPT
• Cracking Pressure: 2-5 psig
• Operating Pressure 0-5000 psig (345 bar)
• Proof Pressure: 7,500 psig (517 bar)
• Burst Pressure: 12,500
• Temperature Range: -40–240°F psi
• Leakage: Zero @ 3 psig to proof

For Your Safety: It is solely the responsibility of the system designer and user to select products suitable for their specific application requirements and to ensure proper installation, operation, and maintenance of these products. Material compatibility, product ratings and application details should be considered in the selection. Improper selection or use of products described herein can cause personal injury or property damage.
