Lenz Filter 1 1/4IN NPT; 10 Micron; 15 PSI Bypass

Name: Lenz Filter 1 1/4IN NPT; 10 Micron; 15 PSI Bypass
Brand: Lenz
SKU: CP-1280-10P
Price: 101.65 USD
Availability: InStock

SKU

CP-1280-10P

$101.65

Filter 1 1/4IN NPT; 10 Micron; 15 PSI Bypass CP-1280-10P

Restrictions / Notifications

No Free Shipping
This item does not qualify for free shipping.
Non-Returnable/Non-Cancelable
This item cannot be canceled or returned once an order has been placed.

More Information
	Specifications Working pressure 150 PSI (10 Bar ) 80 PSI ∆P w/o bypass Operating temperatures -22°F to +212°F (-32°C to +100°C) Flows to 60 GPM (227 LPM) Return Flows to 12 GPM (45 LPM) Suction 1" NPT, 15/8"-12 SAE Ports, 11/2" NPT, 17/8"-12 SAE Element post threads 11/2"-16 UNF or 11/4" BSP Aluminum casting Buna seals Compatible with mineral oils HH, HL, HM, HR, HV, HG, according to ISO 6743/4 6 (lbs), 2-2.5 (kgs) shipping weight Options NPT or SAE Ports 10, 25, micron cellulose, 3, 6, 10, 25 synthetic elements Water absorbing elements 100 wire mesh element Visual or electrical indicators 2.5, 5, 15, 25, PSID., blocked bypass options for return or suction

The dual post thread on this head accepts both European and North American standard filter elements.
