Crouse Hinds WP Connector - 4 Pin - Female Socket

Name: Crouse Hinds WP Connector - 4 Pin - Female Socket
Brand: Crouse Hinds
SKU: WP-4-FS
Price: 240.20 USD
Availability: InStock

SKU

WP-4-FS

$240.20

Restrictions / Notifications

Non-Returnable/Non-Cancelable
This item cannot be canceled or returned once an order has been placed.

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Specs

More Information

Specifications:

Series WP
Ordering Information			Max. AC Volts:300 Max. Amps 7 Cable: 18 AWG/SJO Type
Female WP Order No.	Male WP Order No.	No. of Pins	SJO Cable, AWG Conductors, Length	Locking Sleeve
WP-4-FS	WP-4-MP	4	18 in., 4C/# 18-SJO	Female 58 FLS-1
WP-3-FS	WP-3-MP	3	18 in., 3C/# 18-SJO	Female 58 FLS-1
WP-2-FS	WP-2-MP	2	18 in., 2C/# 18-SJO	Male 58MLS-1

Series WPS
Ordering Information			Max. AC Volts: 600 Max. Amps 7 Cable: SO Type
Female WP Order No.	Male WP Order No.	No. of Pins	SJO Cable, AWG Conductors, Length	Locking Sleeve
WPS-4-FS	WPS-4-MP	4	18 in., 4C/# 18-SJO	Female 58 FLS-2
WPS-3-FS	WPS-3-MP	3	16 in., 3C/# 18-SJO	Female 58 FLS-2
WPS-2-FS	WPS-2-MP	2	18 in.,6C/# 18-SJO	Male 58MLS-2

Applications

Diver umbilical communications, underwater cameras, lighting systems, and instrumentation.

Specifications

Material: Special neoprene, molded
Contacts: Copper alloy-gold plated per ASTM-B-488
Voltage Rating: 300 VDC
Max Amps: 7
Pressure Rating: Up to 20,000 PSI
Cable: 18/4 AWG SJOOW
Cable Length: 18 in.

Information

The Crouse Hinds WP-4-FS - Series WP Waterproof Connectors - 4 Pin - Female Socket is part of the WP Series Waterproof Connectors that have become the commercial diving industry standard for commercial diving helmets, band masks and commercial diver umbilicals. Other typical uses are for underwater cameras, underwater lighting systems, instrumentation. The Crouse Hinds WP and WPS Series waterproof connectors are guaranteed to mate with other name brands of molded waterproof connectors.

The Crouse Hinds WP-4-FS - Series WP Waterproof Connectors - 4 Pin - Female Socket is the original waterproof connector. Typical uses are for underwater cameras, underwater lighting systems, instrumentation. The Crouse Hinds WP and WPS Series waterproof connectors are guaranteed to mate with other name brands of molded waterproof connectors.
