Fibron Power Cable - Price per Reel

Applications:

• Used for power within bell excursions and surface dive umbilicals for communication.

Specifications:

• Standard Reel Continuous Length: 1,640 feet /500 meters (for shorter lengths, contact your sales representative at Amron to obtain pricing)
• Outside Diameter: 10 mm
• Weight in Air: 115 kg/km
• Weight in Sea Water: 35 kg/km
• Density: 1,462 kg/km
• Minimum Bend Radius (static): 65 mm
• Minimum Bend Radius (dynamic): 95 mm
• Minimum Break Strength: N/A
• Red Polyurethane Outer Sheath: 1.9 mm nominal thickness
• Standard Color: Red
• Electrical:
  • 1.5 mm2 Cores
  • Conductor Resistance @ 20°C: 13.5 Ω/km (maximum)
  • Resistance (core–core): 500 MΩ/km (minimum)
  • Resistance (core–screen): 250 MΩ/km (minimum)
  • Operating Voltage: 1000 V (maximum)
