Fibron Mini TV Video Cable - Price per Foot
SHIP NOW
SKU
DCS0005
$5.83
-
Your Price for 1640:$4.87You Save:16%
-
Your Price for 3280:$4.39You Save:25%
Applications:
- Used within bell excursions and surface dive umbilicals for video communication.
Specifications:
- Discounts apply when ordering standard continuous lengths of 1,650 feet/500 meters
- Outside Diameter: 11 mm
- Weight in Air: 170 kg/km
- Weight in Sea Water: 72.5 kg/km
- Density: 1,788 kg/km
- Minimum Bend Radius (static):70 mm
- Minimum Bend Radius (dynamic): 105 mm
- Minimum Break Strength: N/A
- Orange Polyurethane Outer Sheath: 1.4mm nominal thickness
- Standard Color: Orange
- Electrical:
- 1.34mm2 STP
- Conductor resistance @ 20°C: 15.0 Ω/Km (maximum)
- Resistance (core–core): 500 MΩ/Km (minimum)
- Resistance (core–screen): 250 MΩ/Km (minimum)
- Operating voltage: 500 V (maximum)
- 0.5mm2 STP
- Conductor resistance @ 20°C: 41.0 Ω/Km (maximum)
- Resistance (core–core): 500 MΩ/Km (minimum)
- Resistance (core–screen): 250 MΩ/Km (minimum)
- Operating voltage: 500 V (maximum)
- 0.22mm2 TP
- Conductor resistance @ 20°C: 94.0 Ω/Km (maximum)
- Resistance (core–core): 500 MΩ/Km (minimum)
- Resistance (core–screen): 250 MΩ/Km (minimum)
- Operating voltage: 500 V (maximum)
- 1.34mm2 Single Core
- Conductor resistance @ 20°C: 15.5 Ω/Km (maximum)
- Resistance (core–core): 500 MΩ/Km (minimum)
- Resistance (core–screen): 250 MΩ/Km (minimum)
- Operating voltage: 500 V (maximum)
- Mini Coax
- Conductor resistance (inner) @ 20°C: 147.0 Ω/Km (maximum)
- Conductor resistance (inner) @ 20°C: 36.5 Ω/Km (maximum)
- Impedance: 75 Ω
- 1.34mm2 STP
Restrictions / Notifications
- Non-Returnable/Non-Cancelable
This item cannot be canceled or returned once an order has been placed.
Applications:
- Used within bell excursions and surface dive umbilicals for video communication.
Specifications:
- Discounts apply when ordering standard continuous lengths of 1,650 feet/500 meters
- Outside Diameter: 11 mm
- Weight in Air: 170 kg/km
- Weight in Sea Water: 72.5 kg/km
- Density: 1,788 kg/km
- Minimum Bend Radius (static):70 mm
- Minimum Bend Radius (dynamic): 105 mm
- Minimum Break Strength: N/A
- Orange Polyurethane Outer Sheath: 1.4mm nominal thickness
- Standard Color: Orange
- Electrical:
- 1.34mm2 STP
- Conductor resistance @ 20°C: 15.0 Ω/Km (maximum)
- Resistance (core–core): 500 MΩ/Km (minimum)
- Resistance (core–screen): 250 MΩ/Km (minimum)
- Operating voltage: 500 V (maximum)
- 0.5mm2 STP
- Conductor resistance @ 20°C: 41.0 Ω/Km (maximum)
- Resistance (core–core): 500 MΩ/Km (minimum)
- Resistance (core–screen): 250 MΩ/Km (minimum)
- Operating voltage: 500 V (maximum)
- 0.22mm2 TP
- Conductor resistance @ 20°C: 94.0 Ω/Km (maximum)
- Resistance (core–core): 500 MΩ/Km (minimum)
- Resistance (core–screen): 250 MΩ/Km (minimum)
- Operating voltage: 500 V (maximum)
- 1.34mm2 Single Core
- Conductor resistance @ 20°C: 15.5 Ω/Km (maximum)
- Resistance (core–core): 500 MΩ/Km (minimum)
- Resistance (core–screen): 250 MΩ/Km (minimum)
- Operating voltage: 500 V (maximum)
- Mini Coax
- Conductor resistance (inner) @ 20°C: 147.0 Ω/Km (maximum)
- Conductor resistance (inner) @ 20°C: 36.5 Ω/Km (maximum)
- Impedance: 75 Ω
- 1.34mm2 STP
